Pressure booster

The pneumatic pressure booster (pressure intensifier) 0003-0108-0007 increases compressed air pressure where a higher pressure is required than the available plant air supply. In t-s-i.de mixing and dispensing systems, it raises the air pressure to the pneumatic cylinders of the lifting columns: for higher-viscosity materials, this increases the force with which the follower plate is pressed into the drum. The pressure booster is designed for occasional pressure boosting and does not replace a compressor.

Technical data

• Piston diameter: 40 mm
• Operating pressure (inlet): 2.5 to 10 bar
• Outlet pressure: 4.5 to 16 bar
• Pressure control range: 4.5 to 16 bar
• Pressure ratio: up to 1:2
• Pneumatic connections: G1/4 (ports 1 & 2), M7 (port 3)
• Pressure gauge port: G1/8 prepared
• Lubricated air: not permitted
• Ambient temperature: 5 to 60 °C
• Storage temperature: 5 to 60 °C
• Mounting: female-thread mounting, any orientation
