COX VBA 400B MR Adhesive Dispenser (mixing ratio 1:1, 2:1, 4:1, 10:1)

The COX VBA (MR) 400 B compressed-air cartridge gun is a pneumatic cartridge gun for side-by-side cartridges. With 2,20 kN of thrust at 6,80 bar, it applies 2C adhesives and sealants as a bead in mixing ratios of 1:1, 2:1, 4:1 and 10:1.

Technical data

• Drive: pneumatic
• Working pressure: 6,80 bar
• Thrust: 2,20 kN
• Application type: bead application
• Components: 2C
• Mixing ratios: 1:1 | 2:1 | 4:1 | 10:1
• Packaging type: side-by-side cartridge
• Fill volumes: 400 ml | 405 ml | 425 ml | 495 ml
