Static mixer STATOMIX ME 13-32T

The Static Mixer ME 13-32T is a high-performance disposable mixer designed for reliable and homogeneous mixing of two-component adhesives, sealants and resins. The spiral mixing geometry ensures highly efficient and consistent mixing while maintaining a low residual volume.

The Statomix™ ME series is specifically designed for high-pressure applications and is particularly suitable for use in mixing and dispensing systems. The mixer features a 15.9 mm bell inlet, ensuring a secure connection based on industrial standards. It can be mounted on both machines and 2-component cartridges.

With a stepped outlet, this spiral mixer is ideal for precise dispensing applications. The high number of mixing elements ensures excellent mixing quality, even for demanding materials. The use of protective pipes is mandatory for safe operation.

Specification

• Elements: Polyacetal
• Housing: Polypropylene
• Mixer technology: Spiral mixer
• Number of mixing elements: 32
• Outer diameter: 17.00 mm
• Nozzle design: Stepped
• Nozzle opening: 4.00 mm
• Element diameter: 13.00 mm
• Housing inlet: Bell connection 15.90 mm
• Case length: 37.80 cm
• Volume: 33.70 ml
• Pressure resistance: up to 17 bar
• Suitable for industrial dispensing applications

The static mixer is ideal for industrial applications using 2-component adhesives, silicones, polyurethanes and resins.
