MIXPAC DP2X 400-10-50-01 Adhesive Dispenser (mixing ratio 10:1)
Ships today or the next working day
Regular price 540,85 €*
* excl. VAT and shipping
Worldwide shipping Credit card, PayPal or invoice Personal advice: +49 (6373) 819980
Not sure if this dispenser fits your cartridge or foil bag?
Our Cartridge Gun Finder shows you every matching dispenser in just a few steps.
Article number 0001-5203-1100
Weight 3,7 kg
Manufacturer no. DP2X 400-10-50-01
Components 2C
Mixing ratio 10:1
Filling volume 400 ml and 490 ml
Drive Pneumatic
Pressing force 5 kN
Air pressure 6.8 bar
Application type Bead application
Innotech article number ITR3049
The MIXPAC DP2X 400-10-50-01 is a pneumatic 2C cartridge gun for 490 ml twin cartridges in the MIXPAC C and F system, mixing ratio 10:1. Anti-drip system, finely adjustable air control and tool-free cartridge loading. Compatible with C system, F system and BlueLine cartridges. For high-viscosity 2C structural adhesives and sealants.
Technical data
- Cartridge volume: 490 ml (dual)
- Mixing ratio: 10:1
- Maximum thrust: 5.0 kN
- Max. operating pressure: 6.8 bar / 100 psi
- Air inlet: 1/4" NPT
- Weight: 3.7 kg
- Length: approx. 486 mm
- Tool material: cast aluminium and glass-fibre reinforced nylon
Official Innotech Partner
We sell this item as an official web shop partner of Innotech. Repairs and service are handled directly through Innotech.
