MIXPAC DP2X 400-04-50-01 Adhesive Dispenser (mixing ratio 4:1)
Ships today or the next working day
Regular price 540,85 €*
* excl. VAT and shipping
Worldwide shipping Credit card, PayPal or invoice Personal advice: +49 (6373) 819980
Not sure if this dispenser fits your cartridge or foil bag?
Our Cartridge Gun Finder shows you every matching dispenser in just a few steps.
Article number 0001-5203-1200
Weight 3,7 kg
Manufacturer no. DP2X 400-04-50-01
Components 2C
Mixing ratio 4:1
Filling volume 400 ml and 415 ml
Drive Pneumatic
Pressing force 5 kN
Air pressure 6.8 bar
Application type Bead application
Innotech article number ITR3048
Pneumatic 2C dispenser for 400 ml double cartridges in the MIXPAC C- and F-system with a 4:1 mixing ratio. Suitable for the precise processing of high-viscosity 2C adhesives and sealants.
An integrated anti-drip system and adjustable air control ensure clean, controlled material output. The cast-aluminium and glass-fibre-reinforced nylon construction is designed for industrial continuous use.
Technical data
- Drive: pneumatic
- Cartridge volume: 400 ml
- Mixing ratio: 4:1
- Max. thrust: 5.0 kN
- Max. operating pressure: 6.8 bar (100 psi)
- Air inlet: 1/4" NPT
- Material: cast aluminium and glass-fibre-reinforced nylon
- Length: approx. 486 mm
- Weight: 3.7 kg
- System compatibility: MIXPAC C-/F-system
Official Innotech Partner
We sell this item as an official web shop partner of Innotech. Repairs and service are handled directly through Innotech.
