MIXPAC DP2X 400-01-50-01 Adhesive Dispenser (mixing ratio 1:1, 2:1)
Ships today or the next working day
Regular price 540,85 €*
* excl. VAT and shipping
Worldwide shipping Credit card, PayPal or invoice Personal advice: +49 (6373) 819980
Not sure if this dispenser fits your cartridge or foil bag?
Our Cartridge Gun Finder shows you every matching dispenser in just a few steps.
Article number 0001-5203-0100
Weight 3,7 kg
Manufacturer no. DP2X 400-01-50-01
Components 2C
Mixing ratio 1:1 and 2:1
Filling volume 395 ml and 400 ml
Drive Pneumatic
Pressing force 5 kN
Air pressure 6.8 bar
Application type Bead application
Innotech article number ITR3047
The MIXPAC DP2X 400-01-50-01 is a pneumatic 2C cartridge gun for 395 ml and 400 ml side-by-side cartridges in a 1:1 and 2:1 mixing ratio. With a maximum thrust of 5.0 kN at 6.8 bar (100 psi) it handles high-viscosity 2C adhesives and sealants. Piston plates and cartridges can be changed without tools.
Technical data
- Cartridge volume: 395 ml and 400 ml (side-by-side)
- Mixing ratio: 1:1 / 2:1
- Maximum thrust: 5.0 kN
- Max. operating pressure: 6.8 bar / 100 psi
- Air inlet: 1/4" NPT
- Weight: 3.7 kg
- Length: 486 mm
- Tool material: cast aluminium and glass-fibre reinforced nylon
